Output far beyond its size
Put amazing power in the palm of your hand. These compact outboard motors take you to the fun, the fish, or whatever floats your boat – quickly and reliably. Enjoy quick acceleration to go with exhilarating speed. Easy to install and operate, with reliable starting, low vibration, and instant throttle response. It's worry-free boating at its best.
Specifications
HP: 5 HP (3.7 kW)Engine type: 1 cylinderDisplacement: 7.5 CID (123 cc)Full throttle RPM: 4500-5500Fuel induction system: 2-valve pushrod (Overhead Valve)Alternator: 4 amp (50 watt) lighting and chargingRecommended fuel: 87 octane / up to 10% ethanolRecommended oil: Mercury FourStroke Oil 10W-30Engine protection operator warning system: Low oil pressure; Over-revStarting: ManualSteering: TillerShaft length: 20" (508 mm)Gearcase ratio: 2.15:1Dry weight *Lightest model available: 59 lbs (27 kg)CARB star rating: 3Bore and stroke: 2.32 x 1.77" (59 x 45 mm)Ignition: CDI w/electronic spark advanceFuel system: CarburetedCooling system: Water-cooled with thermostatGear shift: F-N-RGearcase options: Sail PowerTrim positions: 6Exhaust system: Through propShallow water drive: YesShallow water trim range: 16 deg.Integrated fuel tank: 0.3 gal. (1.1 L)Remote fuel tank: 3.2 gal. (12 L)Color: Phantom BlackKey Features
Reliability, Portability and Power with the convenience of Propane: Mercury’s all-new 5hp FourStroke Propane outboard provides more convenience and less hassle. With a large 123cc displacement, it offers best-in-class power by delivering a true 5 horsepower. Sail Power model is designed for sailboats, and features an alternator and more thrust.Fourstroke Technology And Mercury: Always moving forward. With boater-driven innovations and technologies. Like the world's first multi-function tiller handle. And a total commitment to corrosion protection, utilizing hard-coat anodizing and a superior multi-step paint process. Mercury FourStroke engines have consistently set the bar for clean, quiet performance and low fuel consumption. Plus, no one has more models to fit your needs.
