2023 Mercury FourStroke 90 HP 2.1L L4 25" Shaft

$11,010
or
Call +1 605-487-7593

Description

Embrace Possibility.
Mercury FourStroke outboard motors are incredibly powerful and efficient, and they feature a wide range of applications. Crafted for less weight and high displacement, they generate abundant torque and immediate power. And because they don’t have to work as hard as heavier engines or those with lower displacement, they make boats plane faster and accelerate better, and they provide optimal fuel efficiency at cruising speed.

Specifications

  • HP: 90 HP (67 kW)
  • Engine type: 8-valve single overhead cam (SOHC) Inline 4
  • Displacement: 128 CID (2.1 L)
  • Full throttle RPM: 5000-6000
  • Air induction: Performance-Tuned Scroll Intake Manifold
  • Fuel induction system: Computer Controlled Multi-Port Electronic Fuel Injection (EFI)
  • Alternator: 35 amp (441 watt) with water-cooled voltage regulator
  • Recommended fuel: Unleaded Regular 87 Octane Minimum (R+M/2); 90 RON 10% Ethanol Maximum
  • Recommended oil: Mercury FourStroke Oil 10W-30
  • Engine protection operator warning system: SmartCraft Engine Guardian
  • Compatible with SmartCraft digital technology: Yes
  • Starting: Smart Start Electric
  • Controls: Mechanical throttle & shift
  • Steering: Big Tiller Compatible; Dual cable mechanical; Hydraulic power steering
  • Shaft length: 25" (635 mm)
  • Gearcase ratio: 2.07:1
  • Dry weight, Lightest model available: 359 lbs (163 kg)
  • CARB star rating: 3
  • Bore and stroke: 3.5 x 3.2" (90 x 81 mm)
  • Ignition: SmartCraft ECM 70 Digital Inductive
  • Fuel system: Electronic Fuel Injection (EFI)
  • Cooling system: Water-cooled with thermostat
  • Gear shift: F-N-R
  • Gearcase options: Standard
  • Trim system: Power Tilt; Power Trim
  • Exhaust system: Through prop
  • Shallow water trim range: 20 deg.
  • Color: Phantom Black
  • Lubrication system: Wet sump
  • Oil Capacity: 5.5 qts (5.2 L)
  • Maximum Trim Range: 22 deg. (-6 deg. to 16 deg.)
  • Maximum Tilt Range: 70 deg. (-6 deg. to 64 deg.)

    • Key Features

  • VesselView Mobile - Overview: Get the most from your Mercury engine with the VesselView Mobile app for iOS and Android! Monitor the basic functions of your outboard motor: rpms, fuel management, miles per gallon, engine hours, coolant temperature, and battery voltage.
  • Discover better boating: Active Trim by Mercury makes boating easier and more enjoyable by automatically trimming your engine. Active Trim simplifies boat operation while improving engine performance and decreasing fuel costs.

    • Specifications

    ManufacturerMercury
    ModelFourStroke 90 HP 2.1L L4 25" Shaft
    Year2023
    ConditionNew
    Engine Type8 valve single overhead cam (SOHC), Inline 4
    Bore x Stroke3.5 x 3.2 in. (90 x 81 mm)
    Displacement128 cu. in. (2.1 L)
    StartingSmart Start Electric
    Shaft Length25 in. (635 mm)
    Weight359 lb. (163 kg) and Up
    Trim MethodPower Tilt: 22 deg. (-6 deg. to 16 deg.) max; Power Trim: 70 deg. (-6 deg. to 64 deg.) max
    Propshaft Horsepower90 HP (67 kW)
    Full Throttle Operating Range5000-6000 RPM
    Gear Ratio / Shift2.07:1
    Fuel InductionComputer Controlled Multi-Port Electronic Fuel Injection (EFI)
    Alternator35 Amp (441 W) with water-cooled voltage regulator
    CoolingWater-cooled with thermostat
    SteeringBig Tiller Compatible; Dual cable mechanical; Hydraulic power steering
