2023 Mercury 60 HP EFI Formula L4

or
Call +1 605-487-7593

Description

Race Proven.
Our mighty 60 EFI FormulaRace packs a punch. This low-emissions, four-stroke competition outboard is the specified engine of the U.I.M. Formula-4S Powerboat World Championship, inshore closed-course racing conducted in conjunction with the F1H2O U.I.M. World Championship series.

Key Features

  • Low-emissions Powerhead: Four-stroke 995cc powerhead has a Three Star rating and produces significantly lower exhaust emissions the two-stroke competition engines it has replaced.
  • EFI: Electronic Fuel Injection produces instant starts and precise metering of fuel at all speeds.
  • Pump Fuel: Produces peak performance on low-cost 87-octane gasoline.
  • Light Weight: A dry weight of just 247 pounds improves race-ready power-to-weight ratio.
  • Best-in-Class Power-to-Weight: Best in class in terms of power to weight ratio for unmatched acceleration, top speed and efficiency.
  • Race Proven: Dominate engine in Class 1 competition at the grueling 24 Hours of Rouen endurance race.
  • Driven To Win!: Exclusive power of the U.I.M. F1H2O World Championship F4 class competition.

    • Specifications

  • Full Throttle RPM: 5500-6000 RPM
  • Rated Hp: 60 HP
  • Cylinders: L4
  • Displacement: 60.8 CID
  • Shaft Length: 15"
  • Trim System: Power Trim
  • Bore & Stroke: 2.56 x 2.95" (65 x 75 mm)
  • Induction System: 2-Valve Per Cylinder, Single Overhead Cam (SOHC)
  • Fuel Requirement: Unleaded Regular 87 Octane Minimum (R+M/2) Or 90 RON 10% Ethanol Maximum
  • Ignition System: ECM 555 Digital Inductive
  • Charging: 18 Amp
  • Starting: Electric (Turn-key)
  • Oil Requirement: Mercury Racing 4-Stroke Oil
  • Gear Ratio: 1.82:1
  • Dry Weight: 247 lbs
  • Engine Type: L4
  • Cooling System: Water-cooled with Thermostat Control
  • Exhaust System: Through Prop
  • Lubrication System: Integrated Wet Sump
  • Gear Shift: F-N-R

    • Specifications

    ManufacturerMercury
    Model60 HP EFI Formula L4
    Year2023
    ConditionNew
    Engine TypeL4
    Bore x Stroke2.56 x 2.95 in. (65 x 75 mm)
    Displacement60.8 cu. in.
    StartingElectric (Turn-key)
    Shaft Length15 in.
    Weight247 lb.
    Trim MethodPower Trim
    Propshaft Horsepower60 HP
    Full Throttle Operating Range5500-6000 RPM
    Gear Ratio / Shift1.82:1
    Fuel Induction2-Valve Per Cylinder, Single Overhead Cam (SOHC)
    Alternator18 Amp
    CoolingWater-cooled with Thermostat Control
    SteeringCable With Wing Plates
